Specs
| Engine | Kawasaki FR730V |
|---|---|
| Horsepower | 24 HP |
| Cylinders | 2 |
| Oil Capacity | 2.1 qt (2.0 L) |
| Drive System | Hydro-Gear® ZT-3100 |
| Fuel Capacity | 5 Gallon |
| Steering Control | Joystick, Twin Lever |
| Stand-up Deck | Standard |
| ContourDTS™ Equipped | Standard |
| Pivoting Front Axle | Standard |
| Tires, Rear | 22×11-10, 22×9.5-10 |
| Tires, Front | 13×6.5-6 |
| Turning Radius | Zero-Turn |
| Ground Speed (Forward / Reverse) | 8 mph/4 mph |
| Length | 79" |
| Height : top of seat back | 48" |
| Width, Tractor (outside rear tires) | 47", 49" |
| Width, Deck w/ Chute | 61", 65", 73" |
| Width, Deck Chute Up | 49", 53", 61" |
| Cutting Width | 48", 52", 60" |
| Cutting Height | 1.5" – 5" (1/4" increments) |
| Deck Construction | Welded 12 Gauge Steel Deck with 10 Gauge Strategic Reinforcements, including high-impact anti-scalp rollers, 3/8" x 2" wear bar on leading & trim edge |
| Deck Engagement | Electric, Ogura® |
| Blade Length | 17", 18.375", 21" |
| Spindle Assembly | Cast aluminum housing; 1" diameter shaft; maintenance free |
| Blade Tip Speed, approx. | 18,000 fpm |
| Weight | 811 – 843 lbs |
| Seat | High Back, Enhanced Comfort Seat with adjustable slides |
| Other Standard Features | Arm Rest, Cup Holder, Electric Start, Front Step, Hitch Plate, Hour Meter |
